Sometimes the smallest change can make the biggest difference, like taking some steps out of an employee's movements through the plant. At other times the changes are bigger and more complex.
The goal of the changes being made at Meridian Yachts, a division of Brunswick Boat Group, is to make employees work better, not harder. "It's not about beating up people to get them to work faster. It's helping them improve their processes so they can work faster, giving them more tools," says Howard Gearheart, plant manager.
Meridian builds motor yachts in a 40-acre plant in Arlington, Wash. The company employs 700, including 74 in the woodworking operation.
In its efforts to rebuild itself into a more efficient and productive company, Meridian has taken to heart the Kaizen method, a process of continuous improvement, along with principles from the Toyota production process and lean and cell manufacturing methods. And the company believes the only way to change and grow is with the full participation of its employees. Meridian's ultimate goal is to provide hassle-free customer satisfaction through quality, safety and productivity, says Gearheart.
Meridian is constantly upgrading and evaluating its equipment, but Gearheart says that is only part of its ongoing effort. "We're changing our people processes and helping our people manage their work, as opposed to us managing them." Gearheart also says that it's not about always buying bigger and bigger machinery. Instead it's about buying what he refers to as right-sized machines.
The evaluation process
Gearheart compares the Toyota process to building a house, which requires a strong foundation and walls before putting on a roof. The roof represents the company's goals. All elements of the process are critical to reaching the company's goals.
"We're doing some pull systems, some Takt Time customer-based production, a little bit of lean and Six Sigma. We're doing a bit of everything and it's going to be a little while before it all comes together," says Gearheart. "The book, The New Shop Floor Management, by Kiyoshi Suzaki, is our bible right now. We're taking some classes. We have many consultants on board who are teaching us the Toyota production system."
Recently, the company finished doing a current-value stream map to determine how long a product takes to produce. A large team goes around the plant and evaluates and documents every step involved in getting a boat built from start to finish. After the map is done, another team comes in and puts together an ideal state, which would be how fast a boat could be done if money and time were no object.
"We come back and build off our ideal state and our current state and come up somewhere in between with a target state," says Gearheart. "In order to make that happen, every one of those processes needs to be improved upon. So you'll have a Kaizen burst."
The spaghetti map
To improve one sub-assembly area in the shop, one Kaizen event performed what is referred to as a spaghetti map. A piece of paper is assigned to an employee along with a map of the building. Then the employee is followed everywhere he goes and tracked on the paper. When the exercise is finished, the marks on the paper look like spaghetti. Then, the distance the employee walks is measured.
"We had Joe walking 10,000 steps in a week. When we got done, we had him down to 1,000 steps," says Gearheart. "Movement is big in this plant. You see people walking everywhere. If you can take out 10 percent of the movement in this plant, that's huge."
The plant is set up with a cell system to keep movement to a minimum. There is a pick cell, where parts are put directly after being cut, where nothing further is required. There is a cherry prep cell, upholstery cell, laminating cell, solid surface cell, finishing cell and assembly cell.
Machines behind the people
All the wood, laminate and solid surface parts are cut on a three-axis, single-head Accu-Router CNC router with an onload/offload system. This machine was purchased a year ago and replaced two older CNC routers the company had used for 10 years. Accu-Router worked with a third party to build the loading system.
The router is set up with a Video Jet printer that prints information directly onto the wood when it is processed. The printing system allows the company to optimize, nest and cut multiple boats with the one machine. The router operates for two shifts and still has capacity available, says Gearheart.
All the nesting programming for the router is done in SigmaNest by the plant engineering staff, while the design is done in corporate engineering. The information is posted directly to the machine and checked by the supervisor for accuracy before the operator does a job.
Meridian added a conveyor belt where scrap pieces are placed as finished cut parts are unloaded, separated into jobs and stacked in carts. After parts are sorted by job, and since parts stay together until the boat is finished, the ink labels are then removed with denatured alcohol. The conveyor system, built by Meridian, takes wood scrap directly into the dumpster, which is emptied a couple of times a day. All wood scrap is recycled.
Another recent addition to the woodworking section of the plant is a Superfici flat-line finishing system. The system has a scanner that scans the part and sends a signal to the spray head, which only sprays where there's a part. Parts go through warm-air drying, a forced-air jet and a UV curing system. The finishing system, purchased in April 2005, uses a Sherwin-Williams waterbased UV curable finish.
Parts are not sanded before the first coat but are sanded between each coat. All the finish is recycled and reused whenever possible on the first three coats. The final topcoat is always new finish. "The Superfici is absolutely wonderful," says Gearheart.
The finishing system is working well right now. But Gearheart says that could change in the future. "You have to right-size what you do," he says. "Instead of having one router and one spray system, I might have three different routers and three smaller spray systems and then only build what I need to build."
The company is working with every tool at its disposal to make employees more productive and happier. Using the different processes as tools for improvement has made the company more profitable than ever. "We're just barely into our journey," says Gearheart. "Right now the most important thing is employee involvement."
